Features
 | 110 dB sensitivity | ||
 500-20000 Hz response | |||
| 100mm(4.0 in) Aluminium voice coil | |||
| 240W continuous program power capacity | |||
Specifications
| TYPE | ND HF DRIVER | Frequency Range | 500-20000 (Hz) | |
| Throat Diameter | 36/1.4 (mm/in) | Recommended Crossover | 800 (Hz) | |
| Rated Impedance | 8 (ohm) | Voice Coil Diameter | 100/4.0 (mm/in) | |
| Minimum Impedance | 8.4 (ohm) | Winding Material | Aluminium | |
| Nominal Power Handling | 120 (Watts) | Former Material | NOMEX | |
| Continuous Power Handling | 240 (Watts) | Diaphragm Material | Titanium | |
| Sensitivity | 110 (dB) | Magnetic Material | Neodymium Inside Slug |
| MORE→ |
Mounting And Shipping
| Overall Diameter | 127/5.0 (mm/in) | N.W.（1 pc） | 1.9 / 4.18 (kg/lb) | |
| Driver Depth | 56/2.2 (mm/in) | G.W.（6 pcs） | 12.2 / 26.89 (kg/lb) | |
| Four M6 holes 90° on 102 mm diameter | 4 x M6 -102 -90° | Shipping size（6 pcs） | 430x320x105 (mm) | |
| MORE→ |
Datasheet Downloads
