Features
 | 112 dB sensitivity | ||
 500-20000 Hz response | |||
| 2x76mm(3.0 in) Aluminium voice coil | |||
| 320W continuous program power capacity | |||
Specifications
| TYPE | ND HF DRIVER | Frequency Range | 500-20000 (Hz) | |
| Throat Diameter | 38/1.5 (mm/in) | Recommended Crossover | 1200 (Hz) | |
| Rated Impedance | 8 (ohm) | Voice Coil Diameter | 2x76/2x3.0 (mm/in) | |
| Minimum Impedance | 5.7 (ohm) | Winding Material | Aluminium | |
| Nominal Power Handling | 160 (Watts) | Former Material | Kapton | |
| Continuous Power Handling | 320 (Watts) | Diaphragm Material | Polyimide | |
| Sensitivity | 112 (dB) | Magnetic Material | Neodymium Ring |
| MORE→ |
Mounting And Shipping
| Overall Diameter | 112/4.41 (mm/in) | N.W.（1 pc） | 2.45 / 5.39 (kg/lb) | |
| Bolt Circle Diameter | 70/2.76 (mm/in) | G.W.（4 pcs） | 12.3 / 27.1 (kg/lb) | |
| Four M6 holes 90° on 82 mm diameter | 4 x M6 -82 -90° | Shipping size（4 pcs） | 350x350x240 (mm) | |
| MORE→ |
Datasheet Downloads
