| Impedance: | |
|---|---|
| Quantity: | |
Features
 | 98.6 dB sensitivity | ||
 32-1000 Hz response | |||
| 152mm(6.0 in) Aluminium voice coil | |||
| 5000W continuous program power capacity | |||
Specifications
| TYPE | ND SUBWOOFER | Frequency Range | 32-1000 (Hz) | |
| Nominal Diameter | 530/21 (mm/in) | Voice Coil Diameter | 153/6.0 (mm/in) | |
| Rated Impedance | 1 (ohm) | Winding Material | Aluminium | |
| Minimum Impedance | 1.7 (ohm) | Former Material | Glass Fibre | |
| Nominal Power Handling | 2500 (Watts) | Winding Depth | 48/1.89 (mm/in) | |
| Continuous Power Handling | 5000 (Watts) | Magnetic Gap Depth | 20/0.79 (mm/in) | |
| Sensitivity | 98.6 (dB) | Magnetic Material | Neodymium Inside Slug |
| MORE→ |
Thiele & Small Parameters
| Fs | 32 (Hz) | Mms | 548 (g) | |
| Re | 0.7 (ohm) | Vas | 177 (liters) | |
| Qms | 12.8 | Sd | 1660 (cm2) | |
| Qes | 0.12 | L1kHz | 0.48 (mh) | |
| Qts | 0.12 | Xmax | ±19 (mm) | |
| Bl | 24.8 (T.M) | EBP | 267 (Hz) |
Mounting And Shipping
| Overall Diameter | 550/ 21.7 (mm/in) | Flange And Gasket Thickness | 16/ 0.63 (mm/in) | |
| Bolt Circle Diameter | 528/ 20.8 (mm/in) | N.W. (1 pc) | 23 / 50.7 (kg/lb) | |
| Mount Baffle Cut-out | 506/ 20.0 (mm/in) | G.W. (1 pc) | 25.3 / 55.8 (kg/lb) | |
| Speaker Depth | 269/ 10.6 (mm/in) | Shipping Size (1 pc) | 630x610x350 (mm) | |
| Mounting Hole | 8 | |||
