| Impedance: | |
|---|---|
| Quantity: | |
Features
 | 97 dB sensitivity | ||
 30-1200 Hz response | |||
| 116mm(4.5 in) Aluminium voice coil | |||
| 3400W continuous program power capacity | |||
Specifications
| TYPE | ND SUBWOOFER | Frequency Range | 30-1200 (Hz) | |
| Nominal Diameter | 460/18 (mm/in) | Voice Coil Diameter | 116/4.5 (mm/in) | |
| Rated Impedance | 2 (ohm) | Winding Material | Aluminium | |
| Minimum Impedance | 2.8 (ohm) | Former Material | Glass Fibre | |
| Nominal Power Handling | 1700 (Watts) | Winding Depth | 44/1.73 (mm/in) | |
| Continuous Power Handling | 3400 (Watts) | Magnetic Gap Depth | 14/0.55 (mm/in) | |
| Sensitivity | 97 (dB) | Magnetic Material | Neodymium Inside Slug |
| MORE→ |
Thiele & Small Parameters
| Fs | 32 (Hz) | Mms | 302 (g) | |
| Re | 1.3 (ohm) | Vas | 155 (liters) | |
| Qms | 5.8 | Sd | 1190 (cm2) | |
| Qes | 0.14 | L1kHz | 0.7 (mh) | |
| Qts | 0.14 | Xmax | ±18.5 (mm) | |
| Bl | 23.6 (T.M) | EBP | 228 (Hz) |
Mounting And Shipping
| Overall Diameter | 460/18 (mm/in) | Flange And Gasket Thickness | 14/0.55 (mm/in) | |
| Bolt Circle Diameter | 443/17.4 (mm/in) | N.W. (1 pc) | 15.3/33.7 (kg/lb) | |
| Mount Baffle Cut-out | 420/16.5 (mm/in) | G.W. (1 pc) | 17.4/39.2 (kg/lb) | |
| Speaker Depth | 261/10.3 (mm/in) | Shipping Size (1 pc) | 540x520x350 (mm) | |
| Mounting Hole | 8 | |||
| MORE→ |
Datasheet Downloads
