| Impedance: | |
|---|---|
| Quantity: | |
Features
 | 100 dB sensitivity | ||
| 250-2000 Hz response | |||
| 65mm(2.5 in) Aluminium voice coil | |||
| 500W continuous program power capacity | |||
Specifications
| TYPE | ND MIDRANGE | Frequency Range | 250-2000 (Hz) | |
| Nominal Diameter | 200/8 (mm/in) | Voice Coil Diameter | 65/2.5 (mm/in) | |
| Rated Impedance | 16 (ohm) | Winding Material | Aluminium | |
| Minimum Impedance | 15.4 (ohm) | Former Material | Glass Fibre | |
| Nominal Power Handling | 250 (Watts) | Winding Depth | 14/0.55 (mm/in) | |
| Continuous Power Handling | 500 (Watts) | Magnetic Gap Depth | 12/0.47 (mm/in) | |
| Sensitivity | 100 (dB) | Magnetic Material | Neodymium Ring |
| MORE→ |
Thiele & Small Parameters
| Fs | 250 (Hz) | Mms | 24 (g) | |
| Re | 10.9 (ohm) | Vas | 1.13 (liters) | |
| Qms | 7.5 | Sd | 222 (cm2) | |
| Qes | 0.65 | L1kHz | 0.97 (mh) | |
| Qts | 0.6 | Xmax | ±4 (mm) | |
| Bl | 25.3(T.M) | EBP | 385 (Hz) |
Mounting And Shipping
| Overall Diameter | 240/9.4 (mm/in) | Flange And Gasket Thickness | 14/0.55 (mm/in) | |
| Bolt Circle Diameter | 221/8.7 (mm/in) | N.W. (1 pc) | 4.5 / 10.0 (kg/lb) | |
| Mount Baffle Cut-out | 200/7.87 (mm/in) | G.W. (1 pc) | 5.9 / 13.0 (kg/lb) | |
| Speaker Depth | 116/4.57 (mm/in) | Shipping Size (1 pc) | 290x290x160 (mm) | |
| Mounting Hole | 6 | |||
| MORE→ |
